Model
VASOL DFD3166GL6D11 dump truck

Item specifics

Maximum speed
88km/h
Total mass (Kg)
31000
Rated load capacity (Kg)
16705,16770,15305,15370,16070,16005
Kerb mass (Kg)
14100,15500,14800
Number of tyres
12

Review

Description

VASOL DFD3166GL6D11 dump truck

SANY JiangShanEV550 construction equipment
VASOL DFD3166GL6D11 dump truck  Advantages Introduction

DONGFENG SPECIAL COMMERCLAL VEHICLE CO., LTD a wholly-owned subsidiary of Dongfeng Group, is an important unit of Dongfeng Group to carry the specialization, specialization, lightweight, electrification, intelligence, networking and sharing of commercial vehicles.

VASOL main business covers a full range of heavy, medium, light and micro tractors, engineering vehicles, trucks, special vehicles, special vehicles, new energy vehicles, etc. The products are widely used in the fields of highway transportation, engineering construction, municipal sanitation, special operations, etc.

 VASOL has occupied the first place in the market for a long time in terms of training car, truck crane and truck crane.

Zhuzhou Yitongda acts as an agent to export high-quality used car products in China Huashen DFD3166GL6D11 dump truck



Product trademark
VASOL
Announcement batch
365
Product name
Dump truck
Product model
DFD3166GL6D11
Total mass (Kg)
16000
Tank volume (m3)
Rated load capacity (Kg)

8590,8525,8370,8305,7870,7805,7905,7970

Overall dimension (mm)
6810,6870,6940,6960,7110,7140,7170,7200,7230,7410,7440,7470,7670,7710,7870,7910,8070,8110,8690,8850,8900,9000×2400,2500,2550×2850,2980,3050,3500
Kerb mass (Kg)

7280,7500,8000,7900

Cargo box size (mm)
4200,4500,4600,4700,4800,5000,5200,5400,5850,6200,6500,6650×2200,2300,2340×500,600,700,800
Number of passengers allowed in the cab (person)
2,3
Total mass of trailer to be towed (Kg)
Approach angle/departure angle (°)
21/20,21/19,21/18
Front overhang/rear overhang (mm)
1310/1760,1310/1830,1310/1860,1310/1880,1310/1910,1310/1930,1310/1960,1310/2060,1310/2190,1310/2290,1310/2340,1310/2440,1310/2490,1310/2590,1410/1600,1410/1750,1410/1800,1410/1840,1410/1870,1410/1900,1410/2000,1410/2190,1410/2340,1410/2490,1410/2580
Axle load (Kg)
5600/10400
Maximum speed (Km/h)
88
remarks
1. The chassis layout at the installation position of urea tank/diesel filter/battery frame/air reservoir is optional along with the chassis, the sun visor is optional, the air filter and air reservoir style are optional, the cab of the same series is optional, and the door drawing and cab font are optional; Optional cargo compartment style, environmental protection cover and tarpaulin;

2. Car dumping mode: rear dumping;

3. Corresponding relationship of overall length and dimension (total length=front overhang+wheelbase+rear overhang) For: 6810=1410+3800+16006960=1410+3800+17507110=1410+3800+19007200=1410+3950+18406940=1310+3800+18306870=1310+3800+17607140=1310+3950+18807170=1310+3950+19106870=1310+3700+18607410=1410+4200+18007710=1410+4500+18007910=1410+4500+20008110=1410+4700+20007230=1410+3950+18707110=1410+3950+1750770=1310+4200+1960740=1310+4200+19307670=1310+4500 8607870=1310+4500+20607870=1310+4700+ 1860,8070=1310+4700+2060,8690=1410+4700+2580,8850=1410+5100+2340,8850=1410+5250+2190,9000=1410+5400+2190,9000=1410+5100+2490,9000=1410+5250+2340,7870=1310+4700+1860,8070=1310+4700+2060,8900=1310+5100+2490,8900=1310+5250+2340,8900=1310+5400+2190,9000=1310+5100+2590,9000=1310+5250+2440,9000=1310+5400+2290; 4. Guardrail material: Q235, connected with frame bolts, rear protective section size (height × Width): 120 × 60 (mm), ground height: 480mm, 460mm, 440mm; 5. The vehicle is equipped with a travel recorder with satellite positioning function; 6. ABS model and manufacturer: 3631010-C2000/Dongke Knorr Commercial Vehicle Braking System (Shiyan) Co., Ltd., J ABS/Jiaozuo Borak Control Technology Co., Ltd., ABS-E 4S/4M/ZF Commercial Vehicle System (Qingdao) Co., Ltd; 7. The declared value of fuel consumption corresponding to YCS06245-60A engine is 22.1L/100km, the declared value of fuel consumption corresponding to YCS06220-60 engine is 22.1L/100km, and the declared value of fuel consumption corresponding to YCS06270-60 engine is 22.1L/100km. 8. This model can be equipped with ETC on-board device
Chassis Model
DFD3166GL6DJ1
Chassis name
Chassis of dump truck
Trade name
VASOL
manufacturing enterprise
Dongfeng Motor Group Co., Ltd
Number of axles
2
Number of tyres
6
Wheelbase (mm)

3700,3800,3950,4200,4500,4700,5100,5250,5400

Tyre specification
9.00R20 16PR,10.00R20 18PR,275/80R22.5 18PR
Number of leaf springs
9/10+8,9/11+8,10/11+8

Front track width (mm)

1810,1840,1860,1880,1900,1910,1940,1960

Fuel type
diesel oil
Rear track width (mm)
1750,1780,1860,1880
Emission standard
GB17691-2018  Ⅵ
Engine model
Engine manufacturer
Guangxi Yuchai Machinery Co., Ltd
Power (Kw)
YCS06245-60A
Guangxi Yuchai Machinery Co., Ltd
6234
180
YCS06220-60
Guangxi Yuchai Machinery Co., Ltd
6234
162
YCS06270-60
Guangxi Yuchai Machinery Co., Ltd
6234
199
