Model
Ruichi ED71

Item specifics

Maximum speed
80km/h
vehicle weight(kg)
2055kg
cabin dimension(L*W*H)mm
3695*1835*1620
max.loading(kg)
1460
total motor power(KW)
90

Review

Description

Ruichi ED71

Ruichi ED70 Pure electric truck Pure electric van
Ruichi ED71  Advantages Introduction

In terms of appearance, the Swiss ED71 adopts a family style design style, which gives people the first impression of being strong and hard-working.

In terms of details, the Swiss ED71 adopts a large number of honeycomb elements and blue elements for embellishment, which makes it fashionable. The beautiful blue logo in the middle is connected with the headlight, and the upper and lower parts are hollow out, but the styles are different, making the upper and lower layers feel different. The rear-view mirrors on both sides are also outlined with hard lines, forming a very muscular feeling.

The rear is a very traditional tailgate body tailgate. The Ruichi New Energy logo and car series name with the new energy blue as the keynote reveal the identity of the new energy of the car, while at the bottom of the rear is a full-size spare tire, which greatly facilitates the driver's tire replacement.

As neat as the appearance, the interior design of the Swiss ED71 is also quite neat and clean, with all the necessary functions. The 1.8m body width makes the cab space more spacious and comfortable for the driver. The embossing process is adopted on the center console, and orange stripes are added to the seats to make the interior more flexible. With the fabric material, the air permeability is good and the texture is soft. The instrument panel uses a dual pointer with a LCD display. The entire LCD screen displays very detailed information, such as vehicle speed, gear position, mileage, and remaining power. The black and white combination can also adapt to the changes in light during driving.

In terms of overall dimensions, the length, width and height of Ruichi fence car are 5990 * 1870 * 2035mm, the cargo box is 3700 * 1770 * 370mm, the thickness of the bottom plate is 1.2/1.5mm, the thickness of the side plate is 1.0/1.2mm, and the thickness of the back plate is 1.0/1.2mm. The rated load of Ruichi ED71 rail car is 1460kg, which almost touches the threshold of light truck legal loading. flatbed truck

Specifications
version
van (60.15kwh)
flatbed(60.15kwh)
refrigerated (60.15)
L*W*H(mm)
5960*1885*2540
5990*1870*2035
5995*1890*2650
body structure
4doors 2seats
2doors 2seats
3doors 2seats
max.speed(km/h)
80
80
80
wheelbase(mm)
3700
3700
3700
Minimum ground clearance(mm)
160
160
160
vehicle weight(kg)
2055
1905
2315
doors(pcs)
2
2
2
seats(pcs)
2
2
2
cabin dimension(L*W*H)mm
3695*1835*1620
3700*1770*370
3615*1720*1600
max.loading(kg)
1310
1460
1050
electro-motor
motor type
permanent magnet sychronous motor
permanent magnet sychronous motor
permanent magnet sychronous motor
total motor power(KW)
90
90
90
Total motor torque(Nm/rpm)
270
270
270
number of drive motor
single motor
single motor
single motor
battery type
lithium ion battery
lithium ion battery
lithium ion battery
Endurance mileage (km)
290
290
290
battery capacity(kwh)
59.78

59.78

59.78

charging time(hr)
fast charge :2.5h
normal charge :10h
fast charge :2.5h
normal charge :10h
fast charge :2.5h
normal charge :10h
gear box
speed class
3-speed
3-speed
3-speed
type of gear box
automatic
automatic
automatic
chassis steering
drive mode
Rear-engine Rear-drive
Rear-engine Rear-drive
Rear-engine Rear-drive
Front suspension type
Leaf spring dependent suspension
Leaf spring dependent suspension
Leaf spring dependent suspension
Rear suspension type
Leaf spring dependent suspension
Leaf spring dependent suspension
Leaf spring dependent suspension
auxiliary type
electric power steering
electric power steering
electric power steering
vehicle structure
non-unitary construction body
non-unitary construction body
non-unitary construction body
