Dongfeng VASOL EQ1160GL6DJ1 truck chassis CHINA 2022
Dongfeng VASOL EQ1160GL6DJ1 truck chassis CHINA 2022
Dongfeng VASOL EQ1160GL6DJ1 truck chassis CHINA 2022
Model
VASOL EQ1160GL6DJ1 truck chassis

Item specifics

Total mass (Kg)
18000
Number of passengers allowed in the cab (person)
2,3
Wheelbase (mm)
4200,4400,3950,4500
Fuel type
diesel oil
Maximum speed (Km/h)
88

Review

Description

Dongfeng VASOL EQ1160GL6DJ1 truck chassis

Dongfeng VASOL EQ1160GL6DJ1 truck chassis
Dongfeng VASOL EQ1160GL6DJ1 truck chassis  Advantages Introduction

DONGFENG SPECIAL COMMERCLAL VEHICLE CO., LTD a wholly-owned subsidiary of Dongfeng Group, is an important unit of Dongfeng Group to carry the specialization, specialization, lightweight, electrification, intelligence, networking and sharing of commercial vehicles.

VASOL main business covers a full range of heavy, medium, light and micro tractors, engineering vehicles, trucks, special vehicles, special vehicles, new energy vehicles, etc. The products are widely used in the fields of highway transportation, engineering construction, municipal sanitation, special operations, etc.

 VASOL has occupied the first place in the market for a long time in terms of training car, truck crane and truck crane.

Zhuzhou Yitongda acts as an agent to export high-quality used car products in China  Dongfeng VASOL EQ1160GL6DJ1 truck chassis



Product trademark
VASOLDongfeng
Announcement batch
355
Product name
Truck chassis
manufacturing enterprise
Truck chassis
Kerb mass (Kg)

4450,4680,4550

Total mass (Kg)

16000

Total mass of trailer to be towed (Kg)


Overall dimension (mm)

7200,7110,7800,7105,7185,7485,7500,7085,6795,6885×2380,2410,2280×2550,2520,2580,2620

Chassis category
Class II
Front overhang/rear overhang (mm)

1300/1700,1300/1410,1300/1950,1300/2000,1285/1620,1285/1700,1285/1400,1285/1800,1300/1800,1285/1110,1285/1400

Number of passengers allowed in the cab (person)
2,3
Wheelbase (mm)

4200,4400,3950,4500

Approach angle/departure angle (°)
17/27,17/32,17/24
Maximum speed (Km/h)
88
Number of axles
2
Tyre specification

9.00R20

Axle load (Kg)
5600/10400
Number of leaf springs

9/11+8,9/10,9/11

Number of tyres
6
Rear track width (mm)

1800,1820,1720

Approach angle/departure angle (°)
17/27,17/32,17/24
emission standard

GB17691-2018 Ⅵ

Front track width (mm)

1820,1920,1940


Fuel type

diesel oil

remarks
1. YCS04180-68 net power is 128kw, YCS04200-68 net power is 143kw, and YCS04160-68 net power is 114kw; 2. Optional lamps, bumpers, front covers, rearview mirrors and other new styles, optional chassis layout and tail lights; 3. Dimension correspondence (total length=front overhang+wheelbase+rear overhang): 7200=1300+4200+1700=1300+3950+1950,7110=1300+4400+1410,7800=1300+4500+2000,7105=1285+4200+1620,7185=1285+4500+1400=1285+4200+1700,7485=1285+4400+1800=1285+4500+1700,7500=1300+4200+2000=1300+4400+1700,7085=1285+4400+1100,6885=1285+4200+1400+1400; 4. ABS model and manufacturer: 3631010-C2000/East Knorr-Bremse Commercial Vehicle Brake System (Shiyan) Co., Ltd., J ABS/Jiaozuo Borak Control Technology Co., Ltd; 5. The vehicle model can be equipped with ETC on-board device; 6. The chassis layout such as battery frame/air reservoir/urea tank/diesel filter is optional, the side spare tire is optional, and the silver (black) rim/tire rim is optional; 7. Select and install new style cab drawing and decoration
Engine model
Engine manufacturer
Displacement (ml)
Power (Kw)

YCS04180-68

Guangxi Yuchai Machinery Co., Ltd

4156

132

YCS04200-68

Guangxi Yuchai Machinery Co., Ltd

4156

147

YCS04160-68

Guangxi Yuchai Machinery Co., Ltd

4156

118
